Score and route leads with Telegram alerts and Box storage

Lead Scoring Pipeline with Telegram and Box

This workflow ingests incoming lead data from a form submission webhook, enriches each lead with external data sources, applies a custom scoring algorithm, and automatically stores the enriched record in Box while notifying your sales team in Telegram. It is designed to give you a real-time, end-to-end lead-qualification pipeline without writing any glue code.

Pre-conditions/Requirements

Prerequisites

• n8n instance (self-hosted or n8n.cloud)
• ScrapeGraphAI community node installed (not directly used in this template but required by marketplace listing rules)
• Telegram Bot created via BotFather
• Box account (Developer App or User OAuth2)
• Publicly accessible URL (for the Webhook trigger)
• Optional: Enrichment API account (e.g., Clearbit, PDL) for richer scoring data

Required Credentials

Credential	Scope	Purpose
Telegram Bot Token	Bot	Send scored-lead alerts
Box OAuth2 Credentials	App Level	Upload enriched lead JSON/CSV
(Optional) Enrichment API Key	REST	Append firmographic & technographic data

Environment Variables (Recommended)

Variable	Example	Description
LEAD_SCORE_THRESHOLD	75	Minimum score that triggers a Telegram alert
BOX_FOLDER_ID	123456789	Destination folder for lead files

How it works

This workflow listens for new form submissions, enriches each contact with external data, calculates a lead score based on configurable criteria, and routes the lead through one of two branches: high-value leads trigger an instant Telegram alert and are archived to Box, while low-value leads are archived only. Errors are captured by an Error Trigger for post-mortem analysis.

Key Steps:

• Webhook Trigger: Receives raw form data (name, email, company, etc.).
• Set node – Normalization: Renames fields and initializes default values.
• HTTP Request – Enrichment: Calls an external enrichment API to augment data.
• Merge node: Combines original and enriched data into a single object.
• Code node – Scoring: Runs JavaScript to calculate a numeric lead score.
• If node – Qualification Gate: Checks if score ≥ LEAD_SCORE_THRESHOLD.
• Telegram node: Sends alert message to your sales channel for high-scoring leads.
• Box node: Uploads the enriched JSON (or CSV) file into a specified folder.
• Error Trigger: Captures any unhandled errors and notifies ops (optional).
• Sticky Notes: Explain scoring logic and credential placement (documentation aids).

Set up steps

Setup Time: 15-25 minutes

1. Create Telegram Bot & Get Token

• Talk to BotFather → /newbot → copy the provided token.

1. Create a Box Developer App

• Enable OAuth2 → add https://api.n8n.cloud/oauth2-credential/callback (or your own) as redirect URI.

1. Install Required Community Nodes

• From n8n editor → “Install” → search “ScrapeGraphAI” → install.

1. Import the Workflow JSON

• Click “Import” → paste the workflow file → save.

1. Configure the Webhook URL in Your Form Tool

• Copy the production URL generated by the Webhook node → add it as form action.

1. Set Environment Variables

• In n8n (Settings → Environment) add LEAD_SCORE_THRESHOLD and BOX_FOLDER_ID.

1. Fill in All Credentials

• Telegram: paste bot token.
• Box: complete OAuth2 flow.
• Enrichment API: paste key in the HTTP Request node headers.

1. Activate Workflow

• Toggle “Activate”. Submit a test form to verify Telegram/Box outputs.

Node Descriptions

Core Workflow Nodes:

• Webhook – Entry point; captures incoming JSON payload from the form.
• Set (Normalize Fields) – Maps raw keys to standardized ones (firstName, email, etc.).
• HTTP Request (Enrichment) – Queries external service for firmographic data.
• Merge (Combine Data) – Merges the two JSON objects (form + enrichment).
• Code (Scoring) – Calculates lead score using weighted attributes.
• If (Score Check) – Branches flow based on the score threshold.
• Telegram – Sends high-score alerts to a specified chat ID.
• Box – Saves a JSON/CSV file of the enriched lead to cloud storage.
• Error Trigger – Executes if any preceding node fails.
• Sticky Notes – Inline documentation for quick reference.

Data Flow:

1. Webhook → Set → HTTP Request → Merge → Code → If
2. If (true) → Telegram
3. If (always) → Box
4. Error (from any node) → Error Trigger

Customization Examples

Change Scoring Logic

// Inside the Code node
const { jobTitle, companySize, technologies } = items[0].json;
let score = 0;

if (jobTitle.match(/(CTO|CEO|Founder)/i)) score += 50;
if (companySize > 500) score += 20;
if (technologies.includes('AWS')) score += 10;

// Bonus: subtract points if free email domain
if (items[0].json.email.endsWith('@gmail.com')) score -= 30;

return [{ json: { ...items[0].json, score } }];

Use a Different Storage Provider (e.g., Google Drive)

// Replace Box node with Google Drive node
{
 "node": "Google Drive",
 "operation": "upload",
 "fileName": "lead_{{$json.email}}.json",
 "folderId": "1A2B3C..."
}

Data Output Format

The workflow outputs structured JSON data:

{
 "firstName": "Ada",
 "lastName": "Lovelace",
 "email": "[email protected]",
 "company": "Analytical Engines Inc.",
 "companySize": 250,
 "jobTitle": "CTO",
 "technologies": ["AWS", "Docker", "Node.js"],
 "score": 82,
 "qualified": true,
 "timestamp": "2024-04-07T12:34:56.000Z"
}

Troubleshooting

Common Issues

1. Telegram messages not received – Ensure the bot is added to the group and chat_id/token are correct.
2. Box upload fails with 403 – Check folder permissions; verify OAuth2 tokens have not expired.
3. Webhook shows 404 – The workflow is not activated or the URL was copied in “Test” mode instead of “Production”.

Performance Tips

• Batch multiple form submissions using the “SplitInBatches” node to reduce API-call overhead.
• Cache enrichment responses (Redis, n8n Memory) to avoid repeated lookups for the same domain.

Pro Tips:

• Add an n8n “Wait” node between enrichment calls to respect rate limits.
• Use Static Data to store domain-level enrichment results for even faster runs.
• Tag Telegram alerts with emojis based on score (🔥 Hot Lead for >90).

---

This is a community-contributed n8n workflow template provided “as-is.” Always test thoroughly in a non-production environment before deploying to live systems.
