Tesla financial market data analyst tool (multi-timeframe technical AI agent)

📊 This AI sub-agent aggregates Tesla (TSLA) trading signals across multiple timeframes using real-time technical indicators and candlestick behavior. It is a core component of the Tesla Quant Trading AI system. Powered by GPT-4.1, it consolidates 15-minute, 1-hour, and 1-day indicators, adds candlestick pattern data, and produces a unified JSON signal for downstream use by the master agent.

⚠️ This agent is not standalone. It is triggered by the Tesla Quant Trading AI Agent via Execute Workflow. 🧠 Requires: 4 connected sub-agents and Alpha Vantage Premium API Key

🔌 Required Sub-Workflows

To use this workflow, you must install:

1. Tesla 15min Indicators Tool
2. Tesla 1hour Indicators Tool
3. Tesla 1day Indicators Tool
4. Tesla 1hour and 1day Klines Tool
5. Tesla Quant Technical Indicators Webhooks Tool (provides Alpha Vantage data)

🧠 What This Agent Does

1. Fetches pre-cleaned 20-point JSON outputs from the 4 sub-agents listed above

2. Analyzes each timeframe individually:

   • 15m: momentum and short-term setups
   • 1h: confirmation of emerging trends
   • 1d: macro positioning and trend alignment
   • Klines: candlestick reversal patterns and volume divergence

3. Generates a structured final signal in JSON with:

   • Trading stance: Buy, Sell, Hold, or Cautious
   • Confidence score (0.0–1.0)
   • Multi-timeframe indicator breakdown
   • Candlestick and volume divergence annotations

📋 Sample Output

{
  "summary": "TSLA momentum is weakening short-term. 1h MACD shows bearish crossover, RSI declining. 1d candles confirm potential reversal setup.",
  "signal": "Cautious Sell",
  "confidence": 0.81,
  "multiTimeframeInsights": {
    "15m": { "RSI": 68.3, "MACD": { "macd": 0.53, "signal": 0.61 }, ... },
    "1h": { "RSI": 65.0, "MACD": { "macd": -0.32, "signal": 0.11 }, ... },
    "1d": { "BBANDS": { ... }, ... },
    "candlestickPatterns": { "1h": "Doji", "1d": "Bearish Engulfing" },
    "volumeDivergence": { "1h": "Bearish", "1d": "Neutral" }
  }
}

🛠️ Setup Instructions

1. Import this workflow into n8n

   • Name it: Tesla_Financial_Market_Data_Analyst_Tool

2. Add Required API Credentials

   • Alpha Vantage Premium (via HTTP Query Auth)
   • OpenAI GPT-4.1 for reasoning and synthesis

3. Link Required Sub-Agents

   • Connect the 4 tool workflows listed above to their respective Tool Workflow nodes
   • Connect the webhook provider for data fetches

4. Set Up as Sub-Agent

   • This workflow must be triggered using Execute Workflow from the parent agent

   • Pass in:

     • message (optional context)
     • sessionId (used for memory continuity)

🧾 Sticky Notes Provided

📘 Tesla Financial Market Data Analyst — Core logic overview 📈 15m / 1h / 1d Tool Notes — Indicator lists + use cases 🕯️ Klines Tool Note — Candlestick and volume divergence patterns 🧠 GPT Reasoning Note — GPT-4.1 handles final synthesis 🧩 Sub-Workflow Trigger — Proper integration with parent agent 🧠 Memory Buffer — Maintains session context across evaluations

🔒 Licensing & Support

© 2025 Treasurium Capital Limited Company The logic, prompt design, and multi-agent architecture are proprietary and IP-protected.

For support or collaboration inquiries: 🔗 Don Jayamaha – LinkedIn 🔗 n8n Creator Profile

🚀 Unify your Tesla trading logic across timeframes—automated, AI-powered, and built for scalers and swing traders.
