Important notice

This workflow is provided as-is. Please review and test before using in production.

1. Workflow Overview

Smart Document Parser for Invoices, Logs or Sensor Reports (PDF/Image to Google Sheets) This n8n workflow automatically parses documents such as invoices, sensor logs or structured PDFs/images (inc...

Best for

Invoice Processing automation workflows
Multimodal AI automation workflows
intermediate n8n builders looking for reusable templates

Tools used

n8n-nodes-base.switch, n8n-nodes-base.googlesheets, n8n-nodes-base.code, @n8n/n8n-nodes-langchain.lmchatgooglegemini, @n8n/n8n-nodes-langchain.chainllm, n8n-nodes-base.webhook, n8n-nodes-base.extractfromfile, n8n-nodes-tesseractjs.tesseractnode

Source and attribution

This workflow is cataloged by N8N Workflows and links back to its original n8n.io source page by WeblineIndia.

Original n8n.io source

1.1 Workflow description

Title: Parse invoices & documents with Gemini AI, OCR, and Google Sheets integration
Workflow name: Parse invoices & documents with Gemini AI, OCR, and Google Sheets integration

Smart Document Parser for Invoices, Logs or Sensor Reports (PDF/Image to Google Sheets)

This n8n workflow automatically parses documents such as invoices, sensor logs or structured PDFs/images (including scanned docs or CSVs), extracts key fields like totals, dates and customer/vendor info using OCR and AI, and writes the structured output into Google Sheets.

Who’s it for

Finance or Ops teams automating invoice processing.
SaaS platforms parsing uploaded reports or documents.
Anyone needing a no-code backend for PDF/image/CSV document parsing.
AI-powered data capture pipelines.

How it works

Webhook Trigger receives file uploads (/uploadDoc)
Switch Node checks the file type:
- If image → Use Tesseract OCR
- If PDF → Use PDF parser
- If CSV → Extract as-is
Extracted text is passed to:
- Google Gemini or Gemini Flash AI model
- Prompt extracts fields like invoice_id, total, customer_name, etc.
JSON string is parsed and cleaned
Data is appended to Google Sheets using appendOrUpdate

How to set up

Create a Google Sheet with columns like:

invoice_id, invoice_date, due_date, customer_name, vendor_name, subtotal, tax_total, total, currency

Connect:
- Google Sheets OAuth
- Google Gemini (PaLM API key) for LLM parsing
Deploy the webhook endpoint: /uploadDoc
Upload sample files (PDFs, images, CSVs) to test
Review and map sheet columns in the Invoice Data node

Requirements

Tool	Purpose
n8n	Automation framework
Google Sheets	To store structured output
Tesseract OCR	For scanned image text extraction
Google Gemini	For natural language parsing

How to customize

Add extraction for line items using structured prompts.
Change prompt to extract sensor readings, log types, or custom keys.
Add support for other file types (e.g., XLSX, DOCX).
Add Slack/Email notifications on success/failure.
Swap Gemini with OpenAI or Hugging Face if preferred.

Add‑ons

Save uploaded files to Google Drive or S3
Add auth for secure uploads
Use charting/dashboard nodes to visualize extracted data
Integrate with billing/accounting software

Use Case Examples

Scenario	What Happens
Invoice Upload (PDF)	Extracts totals, customer, tax data into a Google Sheet
Scanned Receipt (Image)	OCR + LLM extracts structured data
Log File (CSV)	Parses and logs entries into Sheets

Common troubleshooting

Issue	Possible Cause	Solution
`Webhook not triggered`	URL or method mismatch	Use correct POST URL `/uploadDoc`
`Text is blank`	OCR failed	Check image quality or Tesseract config
`Gemini model not returning JSON`	Prompt formatting issue	Ensure prompt ends with valid JSON schema
`Sheet not updated`	Invalid Sheet ID or tab	Double-check sheet credentials and tab name

Need Help?

Need help fine-tuning the Gemini prompt for better field accuracy?
Want to extract full tables, multi-page invoices or convert PDFs to JSON lines?

Our automation team at WeblineIndia can help you extend this into a full-blown document automation pipeline.

1.2 Logical Blocks

This catalog entry is organized from the workflow JSON. The node-level section below shows the executable blocks available for review before importing the template.

2. Block-by-Block Analysis

Block 1 - Check file type

Type / Role: n8n-nodes-base.switch - switch
Config choices: Version 3.2

Block 2 - Invoice data

Type / Role: n8n-nodes-base.googleSheets - googleSheets
Config choices: Version 4.6

Block 3 - Invoice Data

Type / Role: n8n-nodes-base.googleSheets - googleSheets
Config choices: Version 4.6

Block 4 - Transfrom data

Type / Role: n8n-nodes-base.code - code
Config choices: Version 2

Block 5 - Google Gemini Chat Model

Type / Role: @n8n/n8n-nodes-langchain.lmChatGoogleGemini - lmChatGoogleGemini
Config choices: Version 1

Block 6 - Format data from text

Type / Role: @n8n/n8n-nodes-langchain.chainLlm - chainLlm
Config choices: Version 1.7

Block 7 - Webhook Invoice upload

Type / Role: n8n-nodes-base.webhook - webhook
Config choices: Version 2

Block 8 - PDF to Text

Type / Role: n8n-nodes-base.extractFromFile - extractFromFile
Config choices: Version 1

Block 9 - Image to Text

Type / Role: n8n-nodes-tesseractjs.tesseractNode - tesseractNode
Config choices: Version 1

Block 10 - CSV to JSON

Type / Role: n8n-nodes-base.extractFromFile - extractFromFile
Config choices: Version 1

Block 11 - Sticky Note

Type / Role: n8n-nodes-base.stickyNote - stickyNote
Config choices: Version 1

Block 12 - Sticky Note1

Type / Role: n8n-nodes-base.stickyNote - stickyNote
Config choices: Version 1

3. Summary Table

Workflow	Parse invoices & documents with Gemini AI, OCR, and Google Sheets integration
Complexity	intermediate
Nodes	12
Categories	Invoice Processing, Multimodal AI
Author	WeblineIndia
Published	11 Aug 2025

4. Reproducing the Workflow from Scratch

1. Download the workflow JSON

Use the JSON export at /data/workflows/7239/7239.json as the source template for this automation.
2. Import the template into n8n

Open n8n, import the downloaded JSON, and review each node before activating the workflow.
3. Configure credentials and variables

Replace placeholder credentials, API keys, webhook URLs, account IDs, and environment-specific values with your own settings.
4. Test with sample data

Run the workflow manually or in a staging workspace, inspect node output, and confirm downstream systems receive the expected data.
5. Activate and monitor

Enable the workflow only after testing, then monitor executions, errors, and rate limits during the first production runs.

5. General Notes & Resources

Review imported nodes carefully before activation. This catalog entry is intended to help you inspect the workflow structure, understand required services, and find related templates faster.

Node names, credentials, schedules, webhook paths, and external service limits may need adjustment for your workspace.

Download workflow JSON Original n8n.io source Invoice Processing workflows Multimodal AI workflows

Frequently asked questions

What does Parse invoices & documents with Gemini AI, OCR, and Google Sheets integration do?

What do I need before importing this workflow?

Review the workflow JSON, configure any required credentials in n8n, and test the automation in a safe workspace before using it in production.

Can I customize this workflow?

Yes. Use the block-by-block analysis and the downloadable JSON to inspect each node, then adjust credentials, prompts, schedules, filters, or destinations for your Invoice Processing, Multimodal AI use case.

WeblineIndia

216 workflows

Nodes

n8n-nodes-base.switch n8n-nodes-base.googlesheets n8n-nodes-base.code @n8n/n8n-nodes-langchain.lmchatgooglegemini @n8n/n8n-nodes-langchain.chainllm n8n-nodes-base.webhook n8n-nodes-base.extractfromfile n8n-nodes-tesseractjs.tesseractnode

Complexity

intermediate

Published 11 Aug 2025

Likes 0

View on n8n.io Download Workflow

Install path: /data/workflows/7239/7239.json

Share Your Workflow

Have a useful automation to share? Publish it and help the community.

Submit Your Template How to Submit

Related Workflows

Send Stripe payment invoices with Gmail, Google Drive, and WhatsApp

## Quick overview This workflow triggers on successful Stripe payment events, generates and finalizes invoices, then formats and sends invoice details via Gmail, stores invoice PDFs in Google Drive, and notifies an admin through WhatsApp using Rapiwa. ## How it works 1. Triggers when Stripe reports a successful payment, invoice payment, or checkout session completion. 2. Checks whether the payment amount matches the amount received and, if it does not, calculates a payment summary for review. 3. Retrieves the Stripe customer and creates then finalizes a Stripe invoice configured to be sent with Net 30 terms. 4. Fetches invoices created since the event time, iterates through the results, and keeps only Stripe objects that are invoices. 5. Pulls Stripe checkout session line items and formats company, customer, totals, and a custom invoice number for messaging and file naming. 6. Emails the customer the invoice details and PDF link via Gmail, sends an admin WhatsApp alert via Rapiwa, downloads the PDF, and uploads it to Google Drive. ## Setup 1. Add Stripe API credentials, enable the Stripe webhook events used by the trigger, and copy the webhook URL into your Stripe dashboard. 2. Add Gmail OAuth2 credentials and confirm the workflow’s Gmail “send to” mapping matches the email field returned by your Stripe checkout session. 3. Add Google Drive OAuth2 credentials and set the target Drive folder in the Google Drive upload step. 4. Add Rapiwa API credentials and replace the placeholder WhatsApp number with your admin number. 5. Update the company identity, banking details, and any invoice terms (for example days until due) in the invoice formatting and Stripe invoice creation steps. ## Requirements - **Stripe API**: Connects to the Stripe account to listen for webhooks (`payment_intent.succeeded`, `checkout.session.completed`, etc.) and perform API operations (retrieve customers, create invoices, finalize invoices). - **Gmail OAuth2**: Used to send the generated invoice PDF and details to the customer. - *Google Drive OAuth2**: Used to upload and save the generated PDF invoices to a cloud storage folder. - **Rapiwa API**: Used to send WhatsApp notifications to the admin regarding order details and workflow status. ## Customization - Adjust invoice settings in the **Create Stripe Invoice** and **Finalize Invoice** nodes (e.g., due date, collection method, - Customize the customer email content in the **Email (Send Invoice)** node. - Update the **Invoice Save to Google Drive** node's `folderId` to store PDFs in a specific Google Drive folder. ## Additional info • Uses Stripe events for payment validation and invoice generation • Update company details in the **Format Invoice Data** node to match your business • Dynamically fetches purchased items from Stripe sessions • Validates payment amounts before processing invoices • Replace the placeholder WhatsApp number in the **Rapiwa** node with your admin number

View

Send escalating invoice reminders with Notion, Claude, Gmail and Telegram

## Quick overview This workflow runs every morning to pull unpaid invoices from a Notion database, calculates how overdue each one is, uses Anthropic Claude to draft an escalation-appropriate reminder, emails the client via Gmail, updates the invoice record in Notion, and alerts you in Telegram for high-risk late payments. ## How it works 1. Runs every day at 8:00 AM on a schedule. 2. Fetches all unpaid invoice pages from a Notion database and normalizes the key invoice fields into a flat structure. 3. Calculates days overdue from the due date, determines which reminder tier (1/2/3) is due based on thresholds and what was already sent, and skips invoices that are not yet due for the next escalation. 4. Uses Anthropic Claude to generate a subject line and message body that matches the escalation tier. 5. Sends the reminder email to the client via Gmail and updates the Notion page to record the latest reminder tier sent. 6. If the invoice reaches the final (tier 3) escalation, sends a Telegram message to the freelancer to flag the invoice as a payment risk. ## Setup 1. Create or choose a Notion invoice database with the properties referenced by the workflow (including Status, Due Date, Client Email, and Reminder Tier Sent) and paste the database ID into the Notion node configuration. 2. Add credentials for Notion, Anthropic (Claude), Gmail, and Telegram, and select them in their respective nodes. 3. Set your Telegram chat ID in the Telegram node and ensure your Notion Status values match the workflow filter (for example, invoices to remind are marked as “unpaid”).

View

Recover overdue invoices with GPT-4o-mini, Gmail, Google Sheets, and Slack

## Quick overview This workflow runs daily to read overdue invoices from Google Sheets, uses OpenAI (GPT-4o-mini) to draft personalized reminder emails and determine escalation level, sends emails via Gmail, posts Slack alerts for no-invoice runs or AI errors, and logs results back to Google Sheets. ## How it works 1. Runs every 24 hours on a schedule. 2. Reads rows from the “invoices” tab in Google Sheets and, if no invoice value is found, posts a “no overdue invoices” message to Slack. 3. For each invoice, sends the invoice details to OpenAI (GPT-4o-mini) to determine an escalation level, draft an HTML email, and recommend whether to escalate. 4. Parses the AI’s JSON response (falling back to a default reminder if parsing fails) and sends the recovery email to the client via Gmail. 5. If the AI recommends escalation, sends an internal escalation email via Gmail to the legal/AR team with invoice details and the AI summary. 6. Updates the original invoice row in Google Sheets with the escalation level and summary, then appends an audit row to the “Recovery sheet” tab including the email subject, summary, and sent message label ID. 7. If the AI step errors, posts an error alert to Slack and continues processing. ## Setup 1. Add Google Sheets OAuth2 credentials and replace YOUR_GOOGLE_SHEET_ID, ensuring the “invoices” and “Recovery sheet” tabs and columns (Invoice, Client, Email, Amount, Due Date, Days Overdue, Reminders Sent, plus row_number) match the workflow. 2. Add an OpenAI credential for the GPT-4o-mini model. 3. Add Gmail OAuth2 credentials and set the reply-to address ([email protected]) and escalation recipient ([email protected]) to your real emails. 4. Add Slack OAuth2 credentials, replace YOUR_SLACK_CHANNEL_ID, and choose the channel that should receive status and error alerts.

View

Need Custom Automation?

Get help designing a custom n8n workflow that connects your stack and fits your process.

Parse invoices & documents with Gemini AI, OCR, and Google Sheets integration

Workflow preview
